Full Bundle
主なOpen eVisionライブラリのバンドル
© EURESYS S.A. - Subject to change without notice
8/15/2024 Datasheet 主なOpen eVisionライブラリのバンドル /--/uploads/2024/06/Bundle-Full.png)
Main benefits仕様Software
Ordering Information
Offices
|
ハイライト
Full Bundleは、2D産業ビジョン用の主なOpen eVisionライブラリをまとめたコスト効率の良い包括的なソリューションです。広範な画像処理機能を提供できるように作られたこのバンドルには、EasyImage、EasyGauge、EasyFind、EasyMatch、EasyObject、EasyColor、EasyOCR、EasyOCR2，EasyBarCode、EasyMatrixCode、EasyQRCodeなどの強力なツールが含まれています。これらのライブラリによって、認識、測定、識別、および画像解析に関連する多様なニーズを効率的に解決できます。Full Bundleには3DおよびDeep Learningライブラリは含まれません。
Full Bundleの内容
Main benefits
仕様
Software
- Host PC Operating System
Open eVision is a set of 64-bit libraries that require an Intel compatible processor with the SSE4 instruction set or an ARMv8-A compatible processor.
Open eVision can be used on the following operating systems:
Microsoft Windows 11, 10, 8.1, 7 for x86-64 (64-bit) processor architecture
Linux for x86-64 (64-bit) and ARMv8-A (64-bit) processor architectures with a glibc version greater or equal to 2.18
Remote connections
Remote connections are allowed using remote desktop, TeamViewer or any other similar software.
Virtual machines
Virtual machines are supported. Microsoft Hyper-V, Oracle VirtualBox and libvirt hypervisors have been successfully tested.
Only the Neo Licensing System is compatible with virtualization.
Minimum requirements:
2 GB RAM to run an Open eVision application
8 GB RAM to compile an Open eVision application
Between 100 MB and 2 GB free hard disk space for libraries, depending on selected options.
- APIs
Supported programming languages :
The Open eVision libraries and tools support C++, Python and the programming languages compatible with the .NET Framework (C#, VB.NET)
C++ requirements: A compiler compatible with the C++ 11 standard is required to use Open eVision
Python requirements: Python 3.11 or later is required to use the Python bindings for Open eVision
.NET requirements: .NET Framework versions 2.0 to 4.8 are supported
Supported Integrated Development Environments:
Microsoft Visual Studio 2017 (C++, C#, VB .NET, C++/CLI)
Microsoft Visual Studio 2019 (C++, C#, VB .NET, C++/CLI)
Microsoft Visual Studio 2022 (C++, C#, VB .NET, C++/CLI)
QtCreator 4.15 with Qt 5.12
Ordering Information
- Product code - Description
PC4017 Full Bundle for USB dongle
PC4067 Full Bundle for PAR dongle
PC4117 Full Bundle for board licensing
PC4177 Open Full Bundle for USB dongle
PC4227 Open Full Bundle for PAR dongle
PC4327 Open eVision Full Bundle
- Included libraries
EasyBarCode
EasyColor
EasyFind
EasyGauge
EasyImage
EasyMatch
EasyMatrixCode
EasyObject
EasyOCR
EasyOCR2
EasyOCV
EasyQRCode
- Related products
PC6512 eVision/Open eVision USB Dongle (empty)
PC6513 eVision/Open eVision Parallel Dongle (empty)
PC6514 Neo USB Dongle (empty)
