Inspection Bundle
Open eVision 检测库捆绑包
© EURESYS S.A. - Subject to change without notice
8/14/2024 Datasheet Open eVision 检测库捆绑包 /--/uploads/2024/06/Bundle_Inspection.png)
Main benefits规格Software
Ordering Information
Offices
|
亮点
Inspection Bundle 是一款高性价比的 Open eVision 检测库软件包，它为全面的图像检测和分析提供了一套功能强大的工具。该捆绑包涵盖 EasyImage、EasyGauge、EasyMatch、EasyObject 和 EasyColor，其中每个工具都提供专门的功能用来满足各种检测需求。
对于想要利用高效可靠的工具进行高质量图像检测和分析的行业来说，Inspection Bundle 是一种很理想的解决方案。
Inspection Bundle 包含的工具
Main benefits
规格
Software
- Host PC Operating System
Open eVision is a set of 64-bit libraries that require an Intel compatible processor with the SSE4 instruction set or an ARMv8-A compatible processor.
Open eVision can be used on the following operating systems:
Microsoft Windows 11, 10, 8.1, 7 for x86-64 (64-bit) processor architecture
Linux for x86-64 (64-bit) and ARMv8-A (64-bit) processor architectures with a glibc version greater or equal to 2.18
Remote connections
Remote connections are allowed using remote desktop, TeamViewer or any other similar software.
Virtual machines
Virtual machines are supported. Microsoft Hyper-V, Oracle VirtualBox and libvirt hypervisors have been successfully tested.
Only the Neo Licensing System is compatible with virtualization.
Minimum requirements:
2 GB RAM to run an Open eVision application
8 GB RAM to compile an Open eVision application
Between 100 MB and 2 GB free hard disk space for libraries, depending on selected options.
- APIs
Supported programming languages :
The Open eVision libraries and tools support C++, Python and the programming languages compatible with the .NET Framework (C#, VB.NET)
C++ requirements: A compiler compatible with the C++ 11 standard is required to use Open eVision
Python requirements: Python 3.11 or later is required to use the Python bindings for Open eVision
.NET requirements: .NET Framework versions 2.0 to 4.8 are supported
Supported Integrated Development Environments:
Microsoft Visual Studio 2017 (C++, C#, VB .NET, C++/CLI)
Microsoft Visual Studio 2019 (C++, C#, VB .NET, C++/CLI)
Microsoft Visual Studio 2022 (C++, C#, VB .NET, C++/CLI)
QtCreator 4.15 with Qt 5.12
Ordering Information
- Product code - Description
PC4014 Inspection Bundle for USB dongle
PC4064 Inspection Bundle for PAR dongle
PC4114 Inspection Bundle for board licensing
PC4164 Open Inspection Bundle for USB dongle
PC4214 Open Inspection Bundle for PAR dongle
PC4314 Open eVision Inspection Bundle
- Included libraries
EasyColor
EasyGauge
EasyImage
EasyMatch
EasyObject
- Related products
PC6512 eVision/Open eVision USB Dongle (empty)
PC6513 eVision/Open eVision Parallel Dongle (empty)
PC6514 Neo USB Dongle (empty)
